Features

• High Density Filter + Carbon Filter
• €œFollow Me€� Mode
• Interactive Digital LED Display
• R410a Refrigerant
• Optional Wi Fi Control
• Vertical Auto Swing
• Blue Hydrophilic Fins
• Energy Saving 1W Standby
• Service Friendly
• Self Clean Function €“ Indoor
• D.R.E.D Connection
• Self Diagnosis & Auto Protection
• Refrigerant Leakage Detection
• "I-Remote"
• Auto Restart Timer Function Turbo Mode & Sleep Modes

Specifications

• Power supply Ph-V-Hz: 220-240V~ 50Hz 1Ph
• Moisture Removal L/h: 3.0
• Max. current A: 19.5
• Starting current: 44
• Compressor Type: Rotary
• Indoor air flow(turbo/Hi/Mi/Lo/Silence) L/sec: 402/386/355/241/208
• Indoor noise level(turbo/Hi/Mi/Lo/Silence) dB(A): 55/51/45/36/35
• Outdoor noise level (Sound Pressure) dBA@1m: 60
• Outdoor noise level (Sound Power) dB(A): 70
• Refrigerant type(Units pre-charged for 5m pipe run) g: R410A/2150g

Cooling

• Capacity W: 8000 (3200-8800)
• Input power W: 2300(900-2500)
• Run current A: 10.5
• EER W/W: 3.48
• AEER W/W: 3.47
• Standby power W: 1
• SRI: 2.45
• Star: 2.0

Heating

• Capacity W: 8300(3320-9130)
• Input power W: 2350(940-2600)
• Run current A: 10.5
• EER W/W: 3.53
• AEER W/W: 3.53
• standby power W: 1
• SRI: 2.55
• Star: 2.5

Refrigerant Piping

• Liquid side/ Gas side mm(inch): F9.52/F15.9(3/8"/5/8")
• Max. refrigerant pipe length m: 50
• Max. difference in level m: 25

Power Supply - Outdoor Unit

• Room temperature - Indoor(cooling/ heating) °C: 17~32/0~30
• Room temperature - Outdoor(cooling/heating) °C: -15~50/-15~30

Dimensions

• Indoor unit (W x H x D)mm = 1090 x 338 x 235 mm 13.7kg
• Packing (W x H x D)mm = 1165 x 420 x 315 mm 17.8kg
• Outdoor unit (W x H x D)mm = 946 x 810 x 410 mm 62.7kg
• Packing (W x H x D)mm = 1090 x 865 x 500 mm 68.5kg

Warranty

• 5 years
