Features

  • Blue Fin Condenser
  • i-save Mode
  • Quiet Operation
  • Wi-Fi Control (Additional upgrade adapter MAC-558IF required)
  • Vertical Swing
  • R32 Refrigerant
  • Potentially Demand Response Capable
  • Energy Efficient Air Conditioner

Specifications

  • Power Supply (V Phase Hz): 230V Single 50Hz Outdoor unit power supply
  • Starting Current A: 11.3
  • Max.Running Current A: 16.3
  • Indoor Unit - Input W: 55 / 45
  • Outdoor Unit - Breaker Size A: 20

Cooling

  • Capacity (min.-max.) kW: 2.4 - 7.8 - 9.2
  • Input (min.-max.) kW: 0.48 - 2.36 - 3.20
  • AEER/EER kW: 3.30 / 3.31
  • Star Rating: 2.0
  • Running Current A: 10.8
  • Sound Pressure Level: IN - dB: 30 - 37 - 41 - 45 - 53; OUT - dB 55 (69)
  • Air Volume(IN) L/S: 153 - 290

Heating

  • Capacity (min. max.) kW: 2.2 - 9.0 - 11.0
  • Input (min.-max.) kW: 0.43 - 2.55 - 3.65
  • ACOP/COP kW: 3.52 / 3.53
  • Star Rating: 2.5
  • Running Current A: 11.3
  • Sound Pressure Level: IN - dB 30 - 37 - 41 - 45 - 51; OUT - dB 55 (69)
  • Air Volume(IN) L/S: 163 - 340

Ext.Piping

  • Diameter (Gas/Liquid) mm: 12.7 / 6.35
  • Max.Length/Height m: 30 / 15

Guaranteed Operating Range (Outdoor)

  • Cooling: -10 ~ 46 °C
  • Heating: -15 ~ 24 °C

Dimensions

  • Indoor Unit (W x H x D) mm = 1100 x 325 x 238 mm 15.5kg
  • Outdoor Unit (W x H x D) mm = 840 x 880 x 330 mm 20kg

Warranty

  • 5 years
SKU MSZGL80VGDKIT
Barcode # 9316524174228
Brand Mitsubishi Electric
