Features

  • Blue Fin Condenser
  • i-save Mode
  • Quiet Operation
  • Wi-Fi Control (Additional upgrade adapter MAC-558IF required)
  • Vertical Swing
  • R32 Refrigerant
  • Potentially Demand Response Capable
  • Energy Efficient Air Conditioner

Specifications

  • Power Supply (V Phase Hz): 230V Single 50Hz Outdoor unit power supply
  • Starting Current A: 7.4
  • Max.Running Current A: 14.3
  • Indoor Unit - Input W: 35 / 41
  • Outdoor Unit - Breaker Size A: 16

Cooling

  • Capacity (min.-max.) kW: 1.5 - 6.0 - 7.2
  • Input (min.-max.) kW: 0.30 - 1.59 - 2.30
  • AEER/EER kW: 3.77 / 3.77
  • Star Rating: 3.0
  • Running Current A: 7.1
  • Sound Pressure Level: IN - dB: 29 - 37 - 41 - 45 - 49; OUT - dB 55 (69)
  • Air Volume(IN) L/S: 107 - 268

Heating

  • Capacity (min. max.) kW: 2.0 - 6.8 - 9.3
  • Input (min.-max.) kW: 0.03 - 1.67 - 2.84
  • ACOP/COP kW: 4.06 / 4.07
  • Star Rating: 3.5
  • Running Current A: 7.4
  • Sound Pressure Level: IN - dB 29 - 37 - 41 - 45 - 51; OUT - dB 55 (69)
  • Air Volume(IN) L/S: 107 - 290

Ext.Piping

  • Diameter (Gas/Liquid) mm: 12.7 / 6.35
  • Max.Length/Height m: 30 / 15

Guaranteed Operating Range (Outdoor)

  • Cooling: -10 ~ 46 °C
  • Heating: -15 ~ 24 °C

Dimensions

  • Indoor Unit (W x H x D) mm = 923 x 305 x 250 mm 13kg
  • Outdoor Unit (W x H x D) mm = 840 x 880 x 330 mm 53kg

Warranty

  • 5 years

*This product can only be delivered within Sydney Metro.

SKU MSZGL60VGDKIT
Barcode # 9316524174204
Brand Mitsubishi Electric
