Features

  • Blue Fin Condenser
  • i-save Mode
  • Quiet Operation
  • Wi-Fi Control (Additional upgrade adapter MAC-558IF required)
  • R32 Refrigerant
  • Vertical Swing
  • Potentially Demand Response Capable
  • Energy Efficient Air Conditioner

Specifications

  • Power Supply (V Phase Hz): 230V Single 50Hz Outdoor unit power supply
  • Starting Current A: 6.1
  • Max.Running Current A: 14.3
  • Indoor Unit - Input W: 34 / 34
  • Outdoor Unit - Breaker Size A: 16

Cooling

  • Capacity (min.-max.) kW: 1.5 - 4.8 - 6.2
  • Input (min.-max.) kW: 0.30 - 1.17 - 2.07
  • AEER/EER kW: 4.09 / 4.10
  • Star Rating: 4.0
  • Running Current A: 5.2
  • Sound Pressure Level: IN - dB: 28 - 33 - 39 - 44 - 49; OUT - dB 54 (69)
  • Air Volume(IN) L/S: 113 - 282

Heating

  • Capacity (min. max.) kW: 1.6 - 5.8 - 8.0
  • Input (min.-max.) kW: 3.4 - 1.37 - 2.68
  • ACOP/COP kW: 4.22 / 4.23
  • Star Rating: 3.5
  • Running Current A: 6.1
  • Sound Pressure Level: IN - dB 28 - 33 - 38 - 43 - 48; OUT - dB 56 (69)
  • Air Volume(IN) L/S: 113 - 282

Ext.Piping

  • Diameter (Gas/Liquid) mm: 9.52 / 6.35
  • Max.Length/Height m: 30 / 15

Guaranteed Operating Range (Outdoor)

  • Cooling: -10 ~ 46 °C
  • Heating: -15 ~ 24 °C

Dimensions

  • Indoor Unit (W x H x D) mm = 923 x 305 x 250 mm 12.5kg
  • Outdoor Unit (W x H x D) mm = 840 x 880 x 330 mm 53kg

Warranty

  • 5 years

*This product can only be delivered within Sydney Metro.

SKU MSZGL50VGDKIT
Barcode # 9316524174198
Brand Mitsubishi Electric
