General description

• Turbo Drying - Fan assisted moist air extraction
• Style
• Installation type: Built under work top
• Size: XL, 82 cm
• Number of baskets: 3
• 15 place settings
• 8 Steel Construction, SCS+ (Super Cleaning System+)
• Top cutlery tray: Top Tray with Instant Lift; Top Tray with Instant Lift; Rack for
• knives (top); Rack for bowls (top); Telescopic rails for top tray; Handle (top)
• Upper rack type: Premium - two foldable wine shelves, fixed pin rows and one
• foldable glass support
• Lower rack type: Premium - foldable pin rows

Construction & Performance

• Exterior float
• 8 Steel construction
• Hidden heater
• SCS+ (Super Cleaning System+)
• Number of spray arms: 3
• Number of spray zones: 8

Use & Flexibility

• 15 place settings
• Number of baskets: 3
• Top cutlery tray: Top Tray with Instant Lift; Top Tray with Instant Lift™; Rack for
• knives (top); Rack for bowls (top); Telescopic rails for top tray; Handle (top)
• Upper rack type: Premium - two foldable wine shelves, fixed pin rows and one
• foldable glass support
• Easy sliding telescope rails with ball bearings for the upper basket
• Lower rack type: Premium - foldable pin rows
• Dense basket wiring in both upper and lower basket
• Required inlet water pressure: 0,03-1 MPa

Interaction & Control

• Display type: LCD display
• Program memory
• Number of programs: 12
• Delayed start: Variable start delay up to 24 hours
• Status LED light

Programs, options and modes

• 12 Programs: Eco wash; Hygiene wash; Time program; Plastic wash; Heavy wash; Rinse and hold; Sanitation wash; Upper half wash; Lower half wash; Crystal glass; Quick Pro wash; Self-cleaning
• Variable start delay up to 24 hours
• Multi tablet function
• Super rinse
• Time set
• Green mode
• Speed mode
• Night mode
• Intensive mode
• Extra dry
• High temperature
• Super rinse

Design & Integration

• From front adjustable rear foot
• Size: 3/4" Can be connected to hot or cold water
• Niche dimensions (HxWxD): 82 × 60 × 56 cm
• Height setting: 50 mm
• Height setting: 50 mm
• Kick plate adjustable depth: 30-94 mm.

Safety & Maintenance

• Aqua Safe
• Kid Safe - panel
• Rinse-aid indication: Notification in display

Technical data

• Size: 3/4" Can be connected to hot or cold water
• Max. temperature of inflow water: 70 °C
• Noise level: 44 dB(A)re 1 pW
• Reference program: 1
• Total cycle time of reference program (min): 170 min
• Estimated yearly energy consumption: 295 kWh
• Energy consumption reference program: 0.79 kWh
• Energy stars: 3.5
• Water stars: 5
• Water consumption: 12.2 l
• Consumption in off mode: 0.5 W
• Consumption in standby mode: 2 W
• Connection rating: 2000 W
• Voltage: 220-240 V
• Current: 10 amp
• Frequency: 50 Hz
• Required inlet water pressure: 0.03-1 MPa
• Net weight: 44.2 kg

Dimensions

• Product dimensions (HxWxD): 81.9 × 59.6 × 55.9 cm
• Dimensions of packed product (HxWxD): 89 × 64 × 68 cm
• Gross weight: 47.5 kg
• Length electrical cord: 1,825 m
• Depth with door open: 1198 mm
• Length inlet hose: 163 cm
• Length outlet hose: 200 cm

Warranty

• 2 years
